CERVICOM COAXIAL RG-58

Coaxial cables based on MIL-C-17 standard for radio frequency applications

Fire performance

Additional information

Fuego

Information

[tag_icons]

UV RESISTANT

DESINA

[display_cpr_tag_image]

Construction

Conductor
Stranded tinned copper wires
Composition: 19×0,18 mm
Dielectric
Solid polyethylene (PE)
Nominal diameter: 2,95 mm
Screen
Tinned copper wire braid
Coverage: 94 % Aprox.
Outer sheath
PVC (Polyvinyl chloride)
Colour: Black

Technical characteristics

Conductor resistance
41 Ohm/Km (Inner conductor)
Characteristic Impedance
50 Ohm
Capacitance
100 pF/m Max.
Insulation resistance
>1000 MOhm*Km
Velocity of propagation
66%
Attenuation (dB/100m)
13,1 at 50 MHz
21,4 at 100 MHz
55,8 at 400 MHz
92,0 at 1000 MHz
Operating Tª (conductor)
-15°C+70°C
Min. bending radius
10xD

Regulations / Properties

Reference standards
Based on MIL-C-17/28C
Flame Retardant
UNE-EN 60332-1 (IEC 60332-1)
